The TITAN Cartridge Luber™ is a powerful, motor-driven, automatic lubricator which is built on our proven ULTIMATE LUBER™ technology.
The TITAN CL™ is refillable by replacing the standard grease cartridge. These units allow you to be maintenance free for up to 2 years, and for added convenience we have built in low-level sensors that alert the user when the lubricant is near empty. When the grease cartridge needs to be replaced, doing so takes only seconds.
FEATURES & SPECIFICATIONS
- Most powerful auto-luber on the market, developing over 1000psi
- Services single-point applications up to 30’ (9 m) and multi-point applications up to 20’ (6 m)
- Available with replaceable battery packs or optional external power sources (AC and DC)
- Optional Remote Control available to connect to customer machinery or control equipment (e.g. PLC, Contactors, Relays)
- Unit comes mounted on easy-install mounting plate
- Refillable using a standard grease cartridge (no other tools needed)
- Able to service up to 12 lube points with optional progressive distribution block
- Suitable for indoor/outdoor use
- LED operation and warning indicator: (1-RED, 1-GREEN, 1-BLUE)
- Operating range from -20°C to +55°C (-4F to 131F)
- Multiple settings to empty from 15 days to 2 years
- CERTIFICATION: UL/CUL Div. 2 Hazardous Area approved
- NOTE: Low-temp lubricants must be used at low temperatures
