The ELECTRO-LUBER™ is the classic series of automatic lubricators from ATS Electro-Lube, recognized as one of the most reliable solutions on the market. Developed in 1982, it was the first system to use autonomous electrochemical technology, setting the standard in industrial automatic lubrication.
This lubricator is designed to operate under extreme conditions and critical environments, being intrinsically safe and certified for use in hazardous zones, mining, and demanding industries.
Its electrochemical operation allows for constant and precise dosing, ensuring that equipment receives the exact amount of lubricant at the right time, reducing failures and extending the life of components.
Features and Specifications
- Single-point electrochemical automatic lubricator
- Autonomous and independent operation
- Pressure up to 50 psi
- Compatible with any lubricant
- Discharge settings from 15 days up to 1 year
- Remote installation up to 1 m (3 ft)
- Remote control options
- Suitable for indoor and outdoor use
- Water-resistant up to 10 m (33 ft)
- Temperature range: -40°C to +55°C
- Very low backflow rate (<0.001%)
Available in different sizes
- Micro-Luber (60cc): 4-7/8″ high X 3-1/8″ dia.
- Mini-Luber (125cc): 5-5/8″ high X 3-1/8″ dia.
- Budget-Luber (250cc): 6-1/8″ high X 4″ dia.
- Jumbo-Luber (475cc): 6-3/4″ high X 4-3/4″ dia.
Certifications and Safety
- ATEX / UL certification for explosive atmospheres
- Intrinsically safe (Class 1, Groups A, B, C, D, E, F, and G)
- MSHA certification for mining use
- Suitable for industries with special requirements (including food processing)
Benefits
- Ideal for hazardous or explosive zones
- Constant and precise lubrication
- Compatible with any type of lubricant
- Reduces bearing failures
- Lowers maintenance costs
- Improves operational safety
- Allows installation in hard-to-reach areas
- Extends equipment lifespan
- Eliminates downtime due to failures
